Flexo Nomex Braided Sleeving

Soft & Pliable Flame Protection to 662°F

Flexo Nomex Braided Sleeving Features

  • Operating Temperature Range: -320° to 662°F (-196° to 350°C.)
  • Cuts Easily With Scissors
  • Abrasion and Cut Resistant
  • Soft, Pliable & Strong
  • Resists Common Chemicals & Solvents
  • Expands Slightly For Easy Installation
  • Tight Braid For Full Coverage and Protection
  • Melt Temperature: 2,048°F / 1,120°C.
Click for More Details or Description

Require Splice Free? Please Call 1-877-284-7760

Note: Measurements are listed as inside diameter.

Product Details

Woven Flexo Nomex clothing and protective gear has been used for years by race car drivers, fire departments and oil rig personnel to provide that extra level of protection from the dangers that come with working in and around intense flame and heat. Flexo Nomex braided sleeving will do the same for your wires, hoses and cables.

Flexo Nomex braided sleeving will protect your application in temperatures up to 662°F. It is unaffected by short term exposure to most acids, bases, solvents and common engineering chemicals. Despite the soft touch and smooth appearance associated with woven aramid fibers, Nomex sleeving is incredibly strong, with a tensile strength of 90,000 psi.

The densely braided sleeving provides full coverage and protection on even the most exposed applications.

Flexo Nomex sleeving sleeving cuts easily with regular scissors and the smooth surface eases installation even over long wire runs.

Product Specifications

Are we missing the specification you need? Please go to our Contact Us page and submit your question to us, or call 1-877-284-7760

Nominal
Size
Product
Part #
Expansion Range Standard Spool Put-Ups Colors Lbs/
100'
Min. Max. Bulk Shop
1/8"
1/4"
5/16"
3/8"
1/2"
5/8"
3/4"
1"
1 1/4"
1 1/2"
1 3/4"
NXN0.13
NXN0.25
NXN0.31
NXN0.38
NXN0.50
NXN0.63
NXN0.75
NXN1.00
NXN1.25
NXN1.50
NXN1.75
1/16"
1/8"
7/32"
1/4"
5/16"
7/16"
9/16"
3/4"
1"
7/8"
1 3/4"
1/4"
5/16"
7/16"
1/2"
5/8"
7/8"
1"
1 1/8"
2"
1 21/32"
1 55/64"
100'
100'
100'
100'
100'
100'
100'
100'
100'
100'
100'
25'
25'
25'
25'
25'
25'
25'
25'
25'
25'
25'
2
2
2
2
2
2
2
2
2
2
2
0.12
0.50
0.60
0.67
0.91
1.10
1.34
2.42
3.49
4.03
4.76



Physical Properties
Monofilament Thickness (ASTM D-204) NA
Flammability Rating Self-Extinguishing
Recommended Cutting Scissors/Shears
Colors 2
Wall Thickness .016
Tensile Strength - Yarn (ASTM D-2265) lbs. 8
Abrasion Resistance Low
Specific Gravity 1.38
Moisture Absorption % (ASTM D-570) 4



Chemical Resistance

1=No Effect   2=Little Effect   3=Affected   4=More Affected   5=Severely Affected
Aromatic Solvents NA
Alipahtic Solvents NA
Chlorinated Solvents NA
Weak Bases NA
Strong Bases 1
Salt Water (O-S-1926) NA
Hydraulic Fluid (MIL-H-5606) 1
Lubricating Oil (MIL-A-8243) NA
De-Icing Fluid (MIL-A-8243) NA
Strong Acids 2
Strong Oxidants 2
Esters/Ketones NA
UV Light 2
Petroleum 1
Fungus (ASTM G-21) NA
Salts NA



Hard Vacuum Data (ASTM E-595 at 10-5 torr)
TML 3.94
CVCM .18
WVR 2.91
Smoke D-Max (ASTM E-662) NA
Outgassing NA
Oxygen Index (ASTM D-2863) 28



Operating Temperatures
Minimum Continuous -320°F/-196°C
Maximum Continuous (MIL-I-23053) 662°F/350°C
Melt (ASTM D-2117) NA



Other Information
Halogen Free Yes
RoHS Yes
UL/CSA No
