Vectran® Braided Sleeving

A Unique Combination of Properties for Demanding Applications

Vectran® Braided Sleeving Features

  • Self-Extinguishing
  • Melt Temp: 625°F/330°C
  • Medium Outgassing
  • High Abrasion Resistance
  • Resists Common Chemicals & Solvents
  • Recommended Cutting With Kevlar Shears
Click for More Details or Description

Inside Diameters Are Measured as Round Not Flat

Product Details

Vectran® is a high-performance multifilament yarn spun from liquid crystal polymer. Pound for pound Vectran fiber is five times stronger than steel and ten times stronger than aluminum, which makes it the material of choice in demanding applications where other fibers fail to meet performance requirements.

vectran braided sleeving also demonstrates minimal moisture absorption, outstanding cut and abrasion resistance, high dielectric strength, and melt temperature of 625°F.

Vectran® sleeving is used in a wide range of applications, including aerospace, high tech research, industrial protection, marine and medical uses.

Vectran® sleeving is available in Natural color.

Vectran® is a registered trademark of the Kuraray Co., LTD.

Product Specifications

Are we missing the specification you need? Please go to our Contact Us page and submit your question to us, or call 1-877-284-7760

Nominal
Size
Product
Part #
Expansion
Range
Standard
Spool Put-Ups
Colors Lbs/
100'
Min. Max. Bulk Shop
1/8"
1/4"
VEN0.13NT
VEN0.25NT
7/64"
13/64"
9/64"
19/64"
500'
500'
100'
100'
1
1
0.36
0.72



Physical Properties
Flammability Rating Self-Extinguishing
Recommended Cutting Kevlar Shears
Colors 1
Wall Thickness .025
Tensile Strength - Yarn (ASTM D-2265) lbs. 20
Abrasion Resistance high
Specific Gravity 1.4
Moisture Absorption % (ASTM D-570) <.005



Hard Vacuum Data (ASTM E-595 at 10-5 torr)
TML .21
CVCM .00
WVR 1.76
Smoke D-Max (ASTM E-662) NA
Outgassing Medium
Oxygen Index (ASTM D-2863) >30



Chemical Resistance

1=No Effect   2=Little Effect   3=Affected   4=More Affected   5=Severely Affected
Chlorinated Solvents 1
Salt Water (O-S-1926) 1
Hydraulic Fluid (MIL-H-5606) 1
Lubricating Oil (MIL-L-7808) 1
Petroleum 1
Fungus (ASTM G-21) 1



Operating Temperatures
Melt (ASTM D-2117) 625°F/330°C



Other Information
UL/CSA Yes
