Solid Wall Wire Duct

0.5" - 5" Sizes - Completely Protects Cables - No Breakout Slots

Solid Wall Wire Duct Features

  • Lids Included
  • Complete Cable Protection
  • Service Temperature: +5ºF to +140ºF (-15ºC to +60ºC)
  • Standard Mounting Base Slots to DIN 43659
  • Standard Colors: White, Black or Gray (RAL 7030)
  • Approvals: UL, CSA & Lloyds Register
  • RoHS Compliant
  • Composed of Lead Free Material
Click for More Details or Description

Product Details

Solid wall wiring duct provides complete cable and wire protection. It is ideal where no break-outs are required or side wall access is infrequent. It is designed specifically for wire and cable management applications within cabinets and control panels.

Solid Wall wiring duct is made of a lightweight but rigid, self extinguishing PVC that is tested and approved for use underUL94V0 and CSA material standards. Additionally, it is in compliance with RoHS, the European directive on the Restriction of Hazardous Substances.

Product Specifications

Are we missing the specification you need? Please go to our Contact Us page and submit your question to us, or call 1-877-284-7760

MaterialSelf Extinguishing PVCService Temperature Range-15°C to +60°CFlammabilityUL94 V-0 Rated MaterialStandardsBase slots to DIN 43659. CE, RoHS, UL E161178A.
